How to install Transmission with Docker

Transmission is a free, open-source BitTorrent client that is famously light on resources. It has a simple web interface, supports magnet links, encryption and watch folders, and works happily as the download client for Sonarr, Radarr and Lidarr.

In this guide we will run Transmission in Docker using the linuxserver.io image, protect the web UI with a password, point it at a shared /data folder so your *arr apps can hardlink finished downloads, and get it ready to sit behind a reverse proxy.

STEP 1: Find your user and group IDs

Transmission should run as a normal user, not as root. Log in to your Docker host over SSH and run:

id

You will see something like uid=1000(you) gid=1000(you). Make a note of the two numbers; they become PUID and PGID below.

STEP 2: Create the folders

Every app in my media stack shares one data folder, with downloads and the finished library side by side. Create the app's own config folder and the shared layout (skip the second block if you already made it for Sonarr, Radarr or Lidarr):

mkdir -p /path/to/appdata/transmission/config /path/to/appdata/transmission/watch

mkdir -p /path/to/data/{torrents/{movies,tv,music},media/{movies,tv,music}}
sudo chown -R 1000:1000 /path/to/data
sudo chmod -R u=rwX,g=rwX,o=rX /path/to/data

Swap 1000:1000 for your own IDs from STEP 1. When you are done, the shared folder should look like this:

/path/to/data/
    torrents/                     # the download client saves here
        movies/
        tv/
        music/
    media/                        # your finished library (Jellyfin reads this)
        movies/
        tv/
        music/

Finally, I put all my media apps on one shared Docker network so they can reach each other by name (for example, Sonarr reaching http://transmission:9091). If you followed the Jellyfin guide you already have it; otherwise create it once:

docker network create media

STEP 3: The compose file

Create /path/to/appdata/transmission/docker-compose.yml and paste in the following. Use the copy button in the top right corner of the block.

services:
  transmission:
    image: lscr.io/linuxserver/transmission:latest
    container_name: transmission
    hostname: transmission
    restart: unless-stopped
    environment:
      - PUID=1000            # your user ID from STEP 1
      - PGID=1000            # your group ID from STEP 1
      - TZ=Europe/London     # your time zone
      - UMASK=002            # new files are group-writable
      - USER=admin           # web UI username
      - PASS=change-me       # web UI password (change it!)
      - PEERPORT=51413       # must match the port mappings below
      # - HOST_WHITELIST=transmission.example.com
    volumes:
      - /path/to/appdata/transmission/config:/config
      - /path/to/data:/data  # the same mount as Sonarr, Radarr and Lidarr
      - /path/to/appdata/transmission/watch:/watch
    ports:
      - 9091:9091            # web UI and RPC
      - 51413:51413          # incoming peers (TCP)
      - 51413:51413/udp      # incoming peers (UDP)
    networks:
      - media

networks:
  media:
    external: true

STEP 4: The settings explained

STEP 5: Start Transmission

From the folder containing your compose file:

cd /path/to/appdata/transmission
docker compose up -d
docker compose logs -f

Wait until the logs settle down (press Ctrl+C to stop following them; the container keeps running), then check it is up:

docker ps --filter name=transmission

STEP 6: First-run setup

Open http://192.168.1.20:9091 in your browser (use your Docker host's IP) and sign in with the USER and PASS from your compose file.

Out of the box the image saves to /downloads/complete and /downloads/incomplete, which we have not mounted. Fix that first: open the menu, choose Edit Preferences, and on the Torrents tab:

1. Set Download to to /data/torrents.
2. Either untick Use temporary folder, or set it to /data/torrents/incomplete. It must stay inside /data.
3. Close the dialog; Transmission saves preferences as you change them.

Transmission has no categories, so tell each *arr app where to save instead. In Sonarr, Radarr and Lidarr, add Transmission under Settings → Download Clients with host transmission, port 9091, your username and password, and set Directory to /data/torrents/tv, /data/torrents/movies or /data/torrents/music respectively.

STEP 7: Put Transmission behind a reverse proxy

Never forward port 9091 from your router. Put the web UI behind a reverse proxy with HTTPS, keep the USER/PASS login on, or keep it private and use a VPN such as WireGuard or Tailscale.

Option A: Traefik (Docker labels)

If Traefik runs on the same Docker host and is attached to the media network, add these labels to the transmission service. They assume your HTTPS entry point is called websecure and your certificate resolver is called cloudflare; change them to match your Traefik config.

    labels:
      - traefik.enable=true
      - traefik.http.routers.transmission.rule=Host(`transmission.example.com`)
      - traefik.http.routers.transmission.entrypoints=websecure
      - traefik.http.routers.transmission.tls.certresolver=cloudflare
      - traefik.http.services.transmission.loadbalancer.server.port=9091

Option B: Traefik (file provider)

If Traefik runs on a different machine, add a router and service to your dynamic config file instead:

http:
  routers:
    transmission:
      rule: Host(`transmission.example.com`)
      entryPoints:
        - websecure
      tls:
        certResolver: cloudflare
      service: transmission
  services:
    transmission:
      loadBalancer:
        servers:
          - url: http://192.168.1.20:9091

Option C: Nginx Proxy Manager

Add a Proxy Host for transmission.example.com with scheme http, forward hostname transmission (if NPM is on the media network) or 192.168.1.20, and forward port 9091. Request a certificate on the SSL tab and tick Force SSL.

If you turn on HOST_WHITELIST, include your proxy hostname in it (for example transmission.example.com), or Transmission will refuse requests that arrive with that Host header.

Updating Transmission

The latest tag always follows the newest stable release. To update:

cd /path/to/appdata/transmission
docker compose pull
docker compose up -d
docker image prune -f

Troubleshooting

Downloads disappear when the container is recreated. Transmission is still saving to /downloads/... inside the container. Change the download and temporary folders to /data/torrents as in STEP 6.

Torrents show Permission denied. The container user cannot write to /data/torrents. Check docker exec -it transmission ls -ln /data/torrents shows your PUID/PGID and fix it with the commands from STEP 2.

The *arr apps copy instead of hardlinking. Both containers must mount /path/to/data:/data, and the download directory must be under /data/torrents.

421 Misdirected Request through the proxy. HOST_WHITELIST is set but does not include your proxy hostname. Add it, then run docker compose up -d.

port is already allocated when starting. Something else is using 9091 or 51413. Change the left-hand side of the web UI mapping (for example 9092:9091), or change PEERPORT and both sides of the peer mappings together.

That's it! A tiny, tidy torrent client that plays nicely with the rest of your stack. Happy (legal) torrenting! 🧲
